Features:
1.The newly designed synchronous punching and riveting technology greatly improves the qualified rate of finished products.
2.The power is controlled by the hydraulic system to make the work stable and reliable
3.The left and right punches are fed rigidly and synchronously to avoid the useless deformation of the corner assembly process and make the window corner connection more firm.
4.Synchronous feeding mechanism makes machine adjustment easy
5.The distance between the upper and lower corner knives can be adjusted by the thread, which is more convenient for tool setting.
6.Can be equipped with single and multi-point corner knives to make the corners of the thermally insulated aluminum doors and windows more reliable
7.Internal positioning lift
Parameters:
Power 380V 2.2KW
Rated oil pressure 15Mpa
Gas consumption 2L/min
Angle cylinder motion stroke 0～50mm
Splicing gap ≦0.15mm
Air pressure 0.5～0.8Mpa
Fuel tank capacity 20L
Profile Height 120mm
Dimension 1000mm×1500mm×1250mm
Weight 350KG
