Aluminum Corner Key Cutting Machine

Features:

◆ For aluminium corner key cutting.

◆ High efficiency, high precision, for large scale produce.

◆ Automatically cutting and counting.

◆ When power is turned off suddenly, clamping devices keep fixing profiles to protect wokers and machine.

◆ Safe guards get down during cutting, arise after cutting.

◆ Automatically feeding by servo motor driving ball screw.

◆ Imported high quality hard metal saw blade-WEMARO; servo motor and PLC-OMRON; touch screen-Eview; squar guide rail-HIWIN.

   Parameters:

Ø Name Aluminum CNC corner key cutting machine

Ø Model LJMJ-CNC-500B

Ø Power 380V/50HZ/2.6Kw

Ø Rotary speed 2840rpm/min

Ø Air pressure 0.5-0.8MPa

Ø Air consumption 10L/min

Ø Blade specification Φ500xΦ30x4.4 Z=120

Ø Feeding length 5-700mm

Ø Cutting width Max. 140mm

Ø Cutting height Max. 140mm

Ø Weight About 800Kg

Ø Overall dimension About 1500x1600x1600mm
