Features:
◆ Different from other end milling machine, and suitable for various profiles. It also has a special design for the curtain wall profile
◆ One of machines used for aluminum window-door production.
◆ Used for processing aluminium profile end step face and end slot etc.
◆ Convenient tool adjustment to meet different processing requirement. There has a adjust gauge so it is more exactly for adjusting.
◆ Clamp one time can process several profiles, which increased the processing efficiency.
◆ Need not ordering tools when process various profiles, thus can decrease cost and save time.
◆ Large tool diameter, high milling speed and good processing result.
◆ Our machine is specially designed with safe guards, and they clip the profiles tight, even when electricity is cut off suddenly. So it can ensure the operators’ safety.
Parameter:
Voltage: 380V 50HZ
Motor Power: 2.2KW x 4
Feeding motor power: 0.37kw
Air pressure: 0.5-0.8MPa
Blade specification: 350×3.5×30×Z100×1
Rotary speed: 2800r/min
spindle: Φ24mm
Overall dimension: 2900*1220*1700mm
Weight: 1800KG
